– Cảm biến hình ảnh: 1/3 inch CMOS.
– Chuẩn nén hình ảnh: H265+.
– Tốc độ khung hình: 25/30fps@1080P.
– Tầm quan sát hồng ngoại: 30 mét (công nghệ hồng ngoại thông minh).
– Chế độ ngày đêm (ICR), Chống ngược sáng DWDR, chống ngược sáng (BLC), chống nhiễu (3D-DNR).
– Camera hỗ trợ chức năng phát hiện thông minh: Phát hiện chuyển động, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access.
– Hỗ trợ khe cắm thẻ nhớ 128GB.
– Tiêu chuẩn chống bụi nước: IP67 (thích hợp sử dụng trong nhà và ngoài trời).
– Nguồn điện: DC12V.
Xem thêm : Camera WiFi EZVIZ C8PF 2MP, AI, IP67, Quay Quét, Ống kính kép
Đặc tính kỹ thuật
| Camera |
| Image Sensor |
1/3 inch CMOS |
| Max. Resolution |
1920 (H) × 1080 (V) |
| ROM |
16 MB |
| RAM |
64 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.025 lux@F2.0 (Color, 30 IRE)
0.0025 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on) |
| S/N Ratio |
> 56 dB |
| Illumination Distance |
30 m (98.43 ft) |
| Illuminator On/Off Control |
Auto |
| Illuminator Number |
1 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F2.0 |
| Field of View |
2.8 mm: Horizontal: 100°; Vertical: 53°; Diagonal: 120° |
| 3.6 mm: Horizontal: 86°; Vertical: 43°; Diagonal: 102° |
| Iris Control |
Fixed |
| Video |
| Video Compression |
H.264B; H.264; H.264H; H.265 |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Main stream:
1920 × 1080 (1–25/30 fps)
Sub stream:
704 × 576 (1–25 fps)
704 × 480 (1–30 fps) |
| Stream Capability |
2 streams |
| Resolution |
1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H264: 24 kbps–4096 kbps
H265: 9 kbps–4096 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| WDR |
DWDR |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto |
| Noise Reduction |
3D NR |
| Motion Detection |
1024 kbps (1080p) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/180° |
| Mirror |
Yes |
| Audio |
| Built-in MIC |
Yes |
| Built-in Speaker |
Yes |
| Audio Compression |
G.711a; G.711Mu |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change |
| Network |
| Network Port |
RJ-45 (10/100 Base-T) |
| Wi-Fi |
IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G |
| Wireless Range |
Up to 150 m (The performance varies based on actual environment) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; configuration encryption; Digest;
WSSE; account lockout; security logs; generation and
importing of X.509 certification; HTTPS; trusted boot;
trusted execution; trusted upgrade |
| Network Protocol |
IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP |
| Interoperability |
ONVIF; CGI; P2P |
| User/Host |
6 (Total bandwidth: 36 M) |
| Storage |
Micro SD card (support max. 128 GB) |
| Browser |
IE
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Power |
| Power Supply |
12 VDC |
| Power Consumption |
< 6.1 W |
| Environment |
| Operating Temperature |
–30 °C to +50 °C (–22 °F to +122 °F) |
| Operating Humidity |
≤ 95% |
| Storage Temperature |
–40 °C to +60 °C ( –40 °F to +140 °F) |
| Protection |
IP67 |
| Structure |
| Casing |
Front cover: Plastic
Rear: Plastic
Bracket: Metal |
| Product Dimensions |
180 mm × 83.3 mm × 114.8 mm (7.09′ × 3.28′ × 4.52′) |
| Net Weight |
350.1 g (0.77 lb) |
– Bảo hành: 24 tháng.
